55 Inch 450cd/m2 Seamless Landscape Screen 3.5mm Narrow Bezel

55 Inch 450cd/m2 Seamless Landscape Screen 3.5mm Narrow Bezel

Product Details:
Place of Origin: China
Brand Name: TOPADKIOSK/OEM
Certification: CE,FCC.ROSH
Model Number: TPK-W4902
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiate
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 3-5 working days after receipt of your payment
Payment Terms: , , T/T
Supply Ability: 3000PC per month
Contact Now
Detailed Product Description
Place Of Origin:: Guangdong, China (Mainland) Bezel: 3.5mm
Color: 8bit-16.7M Weight: 30kg
Application: Indoor Contrast Ratio: 3000:1
Input Voltag: AC100V~240V 50/60Hz Panel Dimension:: 1077.58(L)*607.8(H)*109(D)
Size: 46/47/49/55 Inch Screen To Screen: 3.8mm
Installation: Rack / Wall-mounted Brightness: 450cd/m2
Highlight:

55 Inch Seamless Landscape Screen

,

450cd/m2 Seamless Landscape Screen

,

3.5mm Narrow Bezel LCD Panel

55 Inch Seamless Landscape screen, video wall with 3.5mm narrow bezel



Super Narrow Bezel for Video Walls

The features an ultra-slim 3.5 mm bezel-to-bezel dimension for video wall applications. With built-in video daisy chaining, a single 1080p source can be used on video walls up to 6×6 in size without the need for any additional external video wall controller. By combining a narrow bezel display with the benefits of a high brightness LED backlight, these displays are ideal for indoor environments that receive a high amount of external daylight such as airports, shopping centers and storefront window displays.

55 Inch 450cd/m2 Seamless Landscape Screen 3.5mm Narrow Bezel 0

55 Inch 450cd/m2 Seamless Landscape Screen 3.5mm Narrow Bezel 155 Inch 450cd/m2 Seamless Landscape Screen 3.5mm Narrow Bezel 255 Inch 450cd/m2 Seamless Landscape Screen 3.5mm Narrow Bezel 3



Panel Specifications
LCD Technology Samsung TFT-LCD
Active Screen Diagonal 55" (1397mm)
Pixel Pitch(WxH) 0.630x0.630mm
Active Display Area(WxH) 1209.6x680.4mm
Panel Dimension(WxHxD) 1215.3x686.1x64mm
Total Bezel Width 5.3mm | 0.208”
Aspect Ratio 16:9
Physical Resolution 1920x1080
Backight System WLED
Luminance(nits) 450cd/sqm
Contrast 3500:1 (typ.)
Viewing Angle H 178°|V 178°
Display Colors 8Bit,16.7M
Refresh Rate 60Hz
Response Time <=6ms
Life(hrs) >60,000(hrs)
MTBF > 100,000h
Surface Anti-glare
Standby Power Consumption <3W
Maximum Power Consumption <=250W
Power Supply AC100~240V 50/60 HZ
Cooling Low noise fans
Heat Dissipation 819 BTU/h (max)
Working Time Capacity 7x24x365hours
Application Area Indoor/Semi Outdoor/Outdoor
Working Temperature 0°C~50°C
Working Humidity 85% non-condensing
Storage Temperature -20-60°C | -4-149°F
Storage Humidity 85% non-condensing
Processor
DVI-I DUAL LINK 1
HDMI 1
VGA 1
CVBS IN 1
CVBS OUT 1
RS232 IN 1
RS232 OUT 2
ISP IN 1
IR IN 1
CODING BUTTON 1
AC IN AC100-240V
Color System Support PAL/NTSC/SECAM
Control Type IR Remote &Software Control
Menu Language English/Chinese(Multiple Language can be customized)




Description
♦ Excellent ultra narrow bezel design with just 3.5mm bezel width between screens
♦ Built-in 3D noise reduction, making the image clean and outline more vivid
♦ Full HD display 3840x2160 display
♦ LED backlit technology brings you perfect visual effect
♦ 4K input supported

Advantages of LCD Video Wall
♦ Reliable quality and low maintenance: Less thermal diffusivity makes the components and parts more stable.
♦ High Definition and clear image: High brightness and contrast make colors brilliant and bright, as well as stable and clear image.
♦ Wide viewing angle: DID LCD panel makes the viewing angle up to 180°.
♦ Low power consumption and low heat radiation
♦ Long service life lowers the cost of usage and maintenance
♦ Innovative and advanced: 42” to 60” Ultra thin bezel LCD video wall, the thinnest bezel up to 1.8mm
♦ Ultathin and lightweighted: The ultra thin and lightweighted design makes it easy to transport and install.
♦ Economic al and practical: High performance and high quality make it cost less.


55 Inch 450cd/m2 Seamless Landscape Screen 3.5mm Narrow Bezel 4



55 Inch 450cd/m2 Seamless Landscape Screen 3.5mm Narrow Bezel 5

55 Inch 450cd/m2 Seamless Landscape Screen 3.5mm Narrow Bezel 6


55 Inch 450cd/m2 Seamless Landscape Screen 3.5mm Narrow Bezel 7

55 Inch 450cd/m2 Seamless Landscape Screen 3.5mm Narrow Bezel 8





55 Inch 450cd/m2 Seamless Landscape Screen 3.5mm Narrow Bezel 9

55 Inch 450cd/m2 Seamless Landscape Screen 3.5mm Narrow Bezel 10



55 Inch 450cd/m2 Seamless Landscape Screen 3.5mm Narrow Bezel 11



FAQ:
Q:How long is the warranty time for your products?
A: Our officially promised warranty time is one whole year after delivery at best.
Q: When will you make the delivery?
A: We can make the delivery within 3-15 working days or depend on the size and quantities of your order.
Q:what brand of screen are you using?
A:we are using Samsung,LG and AUO screen.
Q: Do you have your own enclosure factory?
A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope to provide you with best screen and shape,so OEM is also welcome.
Q:Do you give any discount ?
A: We are Manufacturer, so we are able to give you the best price and best service at the same time.
Q:What payment methods your company accept?
A:We accept most of the payment methods,but mainly accept T/T, WesternUnion,Paypal and
