Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight

Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight

  • Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight
  • Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight
  • Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight
Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight
Product Details:
Place of Origin: China
Brand Name: TOPADKIOSK/OEM
Certification: CE,FCC.ROSH
Model Number: TPK-W4902
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiate
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 3-5 working days after receipt of your payment
Payment Terms: , MoneyGram, T/T
Supply Ability: 3000PC per month
Contact Now
Detailed Product Description
Place Of Origin:: Guangdong, China (Mainland) Bezel: 3.5mm
Color: 8bit-16.7M Weight: 30kg
Application: Indoor Contrast Ratio: 3000:1
Input Voltag: AC100V~240V 50/60Hz Panel Dimension:: 1077.58(L)*607.8(H)*109(D)
Size: 46/47/49/55 Inch Screen To Screen: 1.8mm
Installation: Rack / Wall-mounted Brightness: 450cd/m2
High Light:

2X3 LCD Splicing Video Wall

,

450CD LCD Splicing Video Wall

,

46 Inch LCD Advertising Video Wall

Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight



An LCD video wall is a large visualization surface that is built from multiple LCD displays (also known as ‘tiles’). These individual displays are designed specifically for use in these applications, and differ highly from normal television sets. The biggest differences are the bezel width, the mounting system, and the reliability. Normal television sets are designed to play a few hours per day, these specific panels are expected to play much more. Often even 24/7. And because the environments in which these video walls are deployed are sometimes critical, the uptime needs to be as high as possible.







Panel Specifications
LCD Technology Samsung TFT-LCD
Active Screen Diagonal 55" (1397mm)
Pixel Pitch(WxH) 0.630x0.630mm
Active Display Area(WxH) 1209.6x680.4mm
Panel Dimension(WxHxD) 1215.3x686.1x64mm
Total Bezel Width 5.3mm | 0.208”
Aspect Ratio 16:9
Physical Resolution 1920x1080
Backight System WLED
Luminance(nits) 450cd/sqm
Contrast 3500:1 (typ.)
Viewing Angle H 178°|V 178°
Display Colors 8Bit,16.7M
Refresh Rate 60Hz
Response Time <=6ms
Life(hrs) >60,000(hrs)
MTBF > 100,000h
Surface Anti-glare
Standby Power Consumption <3W
Maximum Power Consumption <=250W
Power Supply AC100~240V 50/60 HZ
Cooling Low noise fans
Heat Dissipation 819 BTU/h (max)
Working Time Capacity 7x24x365hours
Application Area Indoor/Semi Outdoor/Outdoor
Working Temperature 0°C~50°C
Working Humidity 85% non-condensing
Storage Temperature -20-60°C | -4-149°F
Storage Humidity 85% non-condensing
Processor
DVI-I DUAL LINK 1
HDMI 1
VGA 1
CVBS IN 1
CVBS OUT 1
RS232 IN 1
RS232 OUT 2
ISP IN 1
IR IN 1
CODING BUTTON 1
AC IN AC100-240V
Color System Support PAL/NTSC/SECAM
Control Type IR Remote &Software Control
Menu Language English/Chinese(Multiple Language can be customized)




Description
Excellent ultra narrow bezel design with just 3.5mm bezel width between screens
Built-in 3D noise reduction, making the image clean and outline more vivid
Full HD display 3840x2160 display
LED backlit technology brings you perfect visual effect
4K input supported

Advantages of LCD Video Wall
Reliable quality and low maintenance: Less thermal diffusivity makes the components and parts more stable.
High Definition and clear image: High brightness and contrast make colors brilliant and bright, as well as stable and clear image.
Wide viewing angle: DID LCD panel makes the viewing angle up to 180°.
Low power consumption and low heat radiation
Long service life lowers the cost of usage and maintenance
Innovative and advanced: 42” to 60” Ultra thin bezel LCD video wall, the thinnest bezel up to 1.8mm
Ultathin and lightweighted: The ultra thin and lightweighted design makes it easy to transport and install.
Economic al and practical: High performance and high quality make it cost less.


Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight 0



Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight 1

Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight 2


Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight 3

Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight 4





Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight 5

Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight 6



Indoor 450CD 2X3 LCD Splicing Video Wall 46 Inch WLED Backight 7



FAQ:
Q:How long is the warranty time for your products?
A: Our officially promised warranty time is one whole year after delivery at best.
Q: When will you make the delivery?
A: We can make the delivery within 3-15 working days or depend on the size and quantities of your order.
Q:what brand of screen are you using?
A:we are using Samsung,LG and AUO screen.
Q: Do you have your own enclosure factory?
A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope to provide you with best screen and shape,so OEM is also welcome.
Q:Do you give any discount ?
A: We are Manufacturer, so we are able to give you the best price and best service at the same time.
Q:What payment methods your company accept?
A:We accept most of the payment methods,but mainly accept T/T, WesternUnion,Paypal and MoneyGram
